STEERING VALVE LSF-0012817
Product Details

STEERING VALVE

Product code: LSF-0012817

Order STEERING VALVE online with live pricing, stock visibility, and fast UK and Ireland dispatch.

Need a little more info?

Talk to us about fitment, compatibility or alternative parts.

e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

Type of Orbitrol TY-ORBconnection at the side
Total Length L1 (mm)134
Width B (mm)87
Height H (mm)130
Diameter D1 (mm)82
Length L2 (mm)17
Number of splines AC12
Diameter D2 (mm)17.7
Number of Terminals AT-AS4
Type of Thread TA15/8 UNF
Imperial Pitch Pi118
Type of thread TA4M10
Metric Pitch Pm4 (mm)1.25
Center distance C (mm)58

Additional Information

Reference number4503-01

Remark2J,5R (DELUXE CABIN)

Item DescriptionSTEERING VALVE

Model Date1985-09-01 - 1986-08-31
