Product Details

RADIATOR

Product code: LSF-0013001

Order RADIATOR online with live pricing, stock visibility, and fast UK and Ireland dispatch.

Fitment

Suitable for

LINDE

Vehicle model

H25D-01

Serial prefix

393

This item is not available for immediate online checkout, but please get in touch. We can confirm the latest price and availability for you.

e: orders@mhp-parts.com | t: 004428 3885 2503

Talk to us about fitment, compatibility or alternative parts.

e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

Radiator type	vertical
Position radiator cap	without radiator cap connection
Position of input water connection	R
Outer diameter of the input water connection D1 (mm)	34
Position of output water connection	R
Outer diameter of the output water connection D2 (mm)	34
Center distance between input and output water connection L3 (mm)	208
Length without accessories or mounting plates L1 (mm)	640
Height without accessories or mounting plates H1 (mm)	437
Width without accessories or mounting plates W1 (mm)	100
Total length with accessories or mounting plates L2 (mm)	650
Total height with accessories or mounting plates H2 (mm)	490
Total width with accessories or mounting plates W2 (mm)	145
Position oil cooler	K7
Center distance between the 2 connections of the oil cooler L4 (mm)	625
Thickness of core of the radiator W3 (mm)	97
Center distance of the fins L5 (mm)	15

RemarkBEU ENGINE

Item DescriptionRADIATOR

Model SerialN00001 - Z99999

Unit / pack

piece

Dimensions

280 mm L x 580 mm W x 810 mm H
