RADIATOR

Name: TVH RADIATOR 6016678
Brand: TVH
SKU: 6016678
Price: 115.33 GBP
Availability: InStock

Stock: IN STOCK

Your price: £115.33 (ex VAT)

Weight: 7kg

Need a little more info? Talk to us about fitment or alternative parts.
e: orders@mhp-parts.com | t: 004428 3885 2503

Radiator type	vertical
Position radiator cap	R5
Position of input water connection	L
Outer diameter of the input water connection D1 (mm)	35
Position of output water connection	R
Outer diameter of the output water connection D2 (mm)	35
Center distance between input and output water connection L3 (mm)	630
Position draincock	39
Length without accessories or mounting plates L1 (mm)	560
Height without accessories or mounting plates H1 (mm)	475
Width without accessories or mounting plates W1 (mm)	73
Total length with accessories or mounting plates L2 (mm)	635
Total height with accessories or mounting plates H2 (mm)	493
Total width with accessories or mounting plates W2 (mm)	138
Position oil cooler	K3
Center distance between the 2 connections of the oil cooler L4 (mm)	275
Thickness of core of the radiator W3 (mm)	48
Center distance of the fins L5 (mm)	10
Length of the core of the radiator L6 (mm)	465
Height of the core of the radiator H3 (mm)	470
Material collector	plastic
Material core	aluminium
Equipment market EQ-M	material handling parts

Reference number1603-01

Remark15,18

Item DescriptionRADIATOR

Model Date1999-06-01 - 2002-04-30
