RADIATOR

Name: TVH RADIATOR 404417
Brand: TVH
SKU: 404417
Price: 629.93 GBP
Availability: InStock

Part no: 404417

Currently out of stock

This item is currently out of stock, but please get in touch. We can let you know when this will be in stock. Often we can still source this item for you. e: orders@mhp-parts.com | t: 004428 3885 2503

Need a little more info? Talk to us about fitment or alternative parts.
e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

Radiator type	horizontal
Position radiator cap	L2
Position of input water connection	R
Outer diameter of the input water connection D1 (mm)	36.5
Position of output water connection	L
Outer diameter of the output water connection D2 (mm)	36.5
Center distance between input and output water connection L3 (mm)	540
Position draincock	25
Length without accessories or mounting plates L1 (mm)	505
Height without accessories or mounting plates H1 (mm)	500
Width without accessories or mounting plates W1 (mm)	85
Total length with accessories or mounting plates L2 (mm)	565
Total height with accessories or mounting plates H2 (mm)	520
Total width with accessories or mounting plates W2 (mm)	125
Position oil cooler	K5
Center distance between the 2 connections of the oil cooler L4 (mm)	250
Thickness of core of the radiator W3 (mm)	50
Center distance of the fins L5 (mm)	12
Length of the core of the radiator L6 (mm)	490
Height of the core of the radiator H3 (mm)	380
Material collector	copper
Material core	copper
Equipment market EQ-M	material handling parts

RemarkWITH OIL COOLER

Item DescriptionRADIATOR

Model Date1986-04-01 - And Up
