RADIATOR

Product code: LSF-0011977

Order RADIATOR online with live pricing, stock visibility, and fast UK and Ireland dispatch.

This item is not available for immediate online checkout, but please get in touch. We can confirm the latest price and availability for you.

e: orders@mhp-parts.com | t: 004428 3885 2503

Talk to us about fitment, compatibility or alternative parts.

e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

Radiator type	vertical
Position radiator cap	R2
Position of input water connection	L
Outer diameter of the input water connection D1 (mm)	34
Position of output water connection	R
Outer diameter of the output water connection D2 (mm)	34
Center distance between input and output water connection L3 (mm)	655
Position draincock	40
Length without accessories or mounting plates L1 (mm)	630
Height without accessories or mounting plates H1 (mm)	452
Width without accessories or mounting plates W1 (mm)	89
Total length with accessories or mounting plates L2 (mm)	698
Total height with accessories or mounting plates H2 (mm)	470
Total width with accessories or mounting plates W2 (mm)	158
Position oil cooler	K3
Center distance between the 2 connections of the oil cooler L4 (mm)	274
Thickness of core of the radiator W3 (mm)	48.5
Center distance of the fins L5 (mm)	10
Length of the core of the radiator L6 (mm)	502
Height of the core of the radiator H3 (mm)	430
Material collector	plastic
Material core	aluminium
Equipment market EQ-M	material handling parts

REFERENCE NUMBER : 1603-01
