FORK LSF-0013254
FORK LSF-0013254
Product Details

FORK

Product code: LSF-0013254

Order FORK online with live pricing, stock visibility, and fast UK and Ireland dispatch.

Fitment
Suitable for
JCB
Need a little more info?

Talk to us about fitment, compatibility or alternative parts.

e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

New or remanufacturedNew
Type of forkShaft mount fork
Shaft diameter58 mm
Shaft diameter2.3 in
Usable length of the fork47 in
Usable length of the fork1200 mm
Width of the fork100 mm
Width of the fork4.0 in
Thickness of the fork2.0 in
Thickness of the fork50 mm
Capacity per pair (on load centre)4100 kg
Capacity per pair (on load centre)9000 lb
Load centre500 mm
Load centre19.7 in
Fork taperStandard
Total back height from bottom to top570 mm
Total back height from bottom to top22 in

Additional Information

Product information

Unit / pack
set 2 piece
Dimensions
110 mm L x 620 mm W x 1250 mm H

Useful notes

  • This is a product with exceptional dimensions. It is possible that the chosen carrier will be adjusted and transport cost and delivery time can/may change.
  • The delivered unit is a set
  • Eye OD 90mm Eye ID 57.70mm center eye height: 570mm 25mm offset
  • Fork type: PIN-type fork
  • Back height from bottom of fork to the centre of the tube H2 (mm): 570
  • Usable length of the fork L1-M (mm): 1200
  • Width of fork W1-M (mm): 100
  • Thickness fork TH1-M (mm): 50
  • Total back height from bottom to top of the fork back H1 (mm): 570
  • Capacity/pair on load centre Q (kg): 4100
  • Load centre LC (mm): 500
  • Suspension alignment: offset
  • Width of the tube W2 (mm): 100
  • Internal diameter of the tube D2 (mm): 58
