Position of input water connection
L
Outer diameter of the input water connection D1 (mm)
37
Position of output water connection
R
Outer diameter of the output water connection D2 (mm)
37
Center distance between input and output water connection L3 (mm)
690
Length without accessories or mounting plates L1 (mm)
620
Height without accessories or mounting plates H1 (mm)
488
Width without accessories or mounting plates W1 (mm)
75
Total length with accessories or mounting plates L2 (mm)
690
Total height with accessories or mounting plates H2 (mm)
536
Total width with accessories or mounting plates W2 (mm)
140
Position oil cooler
K2-K3
Center distance between the 2 connections of the oil cooler L4 (mm)
253
Thickness of core of the radiator W3 (mm)
57.55
Center distance of the fins L5 (mm)
10
Material collector
plastic
