Shape of the contactor
round shape 1
Maximum length of the contactor L1 (mm)
74
Maximum width of the contactor W1 (mm)
39
Maximum height of the contactor H1 (mm)
51
Maximum diameter of the contactor D1 (mm)
34
Voltage of the solenoid (V)
48
Type of current
direct current
Resistance of the solenoid (Ohm)
67.7
Number of connections on the solenoid
2
Type of connection on the solenoid
blade 6,3mm
Number of contact connections
2
Type of contact connection
outer thread
Pitch metric of outer thread (mm)
1
Right / left outer thread
right-handed
Pitch metric of inner thread (mm)
1
Right/left inner thread
right-handed
External diode present
NO
External resistor present
NO
Number of normal open contacts (NO)
1
Auxiliary contact present
NO
Magnetic blow outs present
NO
Shortest center distance between mounting holes C1 (mm)
58
Shape mounting surface
flat
