Type of brake drum TY
drum and hub in one piece
Maximum outer diameter D1 (mm)
342
Inner diameter (position brake lining) D2 (mm)
310
Total height (top - bottom) H1 (mm)
245
Largest inner diameter D3 (mm)
140
Height of brake lining diameter H2 (mm)
70.5
