Type of brake drum TY
drum and hub in one piece
Maximum outer diameter D1 (mm)
340
Inner diameter (position brake lining) D2 (mm)
310
Total height (top - bottom) H1 (mm)
164
Largest inner diameter D3 (mm)
105
Height of brake lining diameter H2 (mm)
68
