KNUCKLE STEERING RH TCM FD100Z7/Z8

Product code: LSF-0009852

Order KNUCKLE STEERING RH TCM FD100Z7/Z8 online with live pricing, stock visibility, and fast UK and Ireland dispatch.

Designed for: TCM

This item is not available for immediate online checkout, but please get in touch. We can confirm the latest price and availability for you.

e: orders@mhp-parts.com | t: 004428 3885 2503

Talk to us about fitment, compatibility or alternative parts.

e: orders@mhp-parts.com | t: 004428 3885 2503

Specifications

First finished diameter D1 (mm)	55
Second finished diameter D2 (mm)	75
Third finished diameter D3 (mm)	95
Thread size	M55
Pitch metric (mm)	2
Diameter king pin D4 (mm)	45
Total height of the knuckle housing H1 (mm)	122
Smallest diameter of steering connection D5 (mm)	32
Biggest diameter of steering connection D6 (mm)	34
Length steer connection L3 (mm)	30
Length spindle axle L4 (mm)	138
Position steering knuckle	right

KNUCKLE STEERING LH

TCM

FD100Z7 FG100ZZ

FD100Z8 FG100Z8
