Type of application
gas spring
Type of gas spring/shock absorber
locking type
Piston rod diameter D1 (mm)
10
Centre distance C1 (mm)
600
Operational length L2 (mm)
270
Type of connection piston rod side
type F
Bushing height H2a (mm)
6
Overall length L3a (mm)
50.5
Connecting distance L4a (mm)
40
Mounting thickness Ta (mm)
3
Thread of mounting TA1a
M8
Type of connection piston side
type F
Diameter of the mounting eye D3b (mm)
9.5
Connecting distance L4b (mm)
40
Mounting thickness Tb (mm)
3
Thread of mounting TA1b
M8
