Position of input water connection
R
Outer diameter of the input water connection D1 (mm)
36
Position of output water connection
L
Outer diameter of the output water connection D2 (mm)
36
Center distance between input and output water connection L3 (mm)
628
Length without accessories or mounting plates L1 (mm)
570
Height without accessories or mounting plates H1 (mm)
475
Width without accessories or mounting plates W1 (mm)
70
Total length with accessories or mounting plates L2 (mm)
625
Total height with accessories or mounting plates H2 (mm)
510
Total width with accessories or mounting plates W2 (mm)
117
Position oil cooler
without
Thickness of core of the radiator W3 (mm)
36
Center distance of the fins L5 (mm)
10
