Type of the retaining ring
tapered
Type of the tapered retaining ring
axial assembled
Main shape of the tapered retaining ring
DHO
Secondary shape of the tapered retaining ring
DHO-01
Type of assembly of the retaining ring
internal
External diameter of the ring in the unstressed state D2 (mm)
20.5
Thickness of the ring TH1 (mm)
1
Maximum radial section width W2 (mm)
2.2
Lug hole diameter D6 (mm)
2
Minimum housing diameter D4 (mm)
19
Maximum housing diameter D4 (mm)
19
Groove diameter D5 (mm)
20
