Type of the retaining ring
constant section
Cross section of the constant section retaining ring
rectangular (standing)
Shape of the constant section retaining ring
circular
Type of end 1 of the constant section retaining ring
001
Type of end 2 of the constant section retaining ring
002
Type of assembly of the retaining ring
internal
Internal diameter of the ring in the unstressed state D1 (mm)
215.2
External diameter of the ring in the unstressed state D2 (mm)
225.2
Thickness of the ring TH1 (mm)
3
Maximum radial section width W2 (mm)
5
Minimum housing diameter D4 (mm)
220
Maximum housing diameter D4 (mm)
220
Groove diameter D5 (mm)
223
