TRACTION WHEEL 39933800

TRACTION WHEEL

Part no: 39933800

Stock: IN STOCK

Designed for: LINDE

Your price: £81.84 (ex VAT)

Weight: 7.552kg


Specifications

Sort of traction wheel SRT-WH
standard traction wheel
Diameter of the wheel D1 (mm)
230
Width of the wheel W1 (mm)
90
Diameter of the rim D2 (mm)
186
Width of the rim W2 (mm)
90
Shaft diameter D8 (mm)
45
Inner offset of the flange OFF-IN (mm)
74
Outer offset of the flange OFF-OUT (mm)
6
Thickness of the flange TH-FL (mm)
10
Material of the wheel (grouped) MAT-WH
polyurethane
Wheel material detail MAT-DET
vulkollan®: For heavy duty 2-3 shifts/day/cold store with less noise, less vibrations
Hardness HR (shore A)
92
Shape of the tread SH-TRED
crowned
Radius of the crowned tread RAD-TRED
R250
Wheel profile PROF-WH
smooth
Material of the rim MAT-RIM
cast iron
Groove for seal ring present SEAL-PR
NO
Cam present CAM-PR
NO
Number of bolt holes QTY-BO
5
Type of bolt hole TY-BO
conical countersunk
Diameter of the bolt holes D13 (mm)
13
Biggest diameter of the bolt holes D14 (mm)
23
Height of the countersunk bolt hole H5 (mm)
5
Pitch circle diameter D15 (mm)
70
Centre distance of the bolt holes C1 (mm)
41.2
Rim and tyre RIMTYR
NO
Suitable for coldstore use SUF
YES
One side is closed CL
NO
Maximum load LOAD (kg)
1750
Maximum speed at maximum load V (km/h)
6
