Sort of loadwheel SRT-WH
standard wheel
Mounting of the wheel MOU-WH
with bearing
Diameter of the wheel D1 (mm)
85
Width of the wheel W1 (mm)
105
Diameter of the bearing chamber 1 D3 (mm)
55
Diameter of the bearing chamber 2 D4 (mm)
55
Type of bearing 1 (prefix) PREF1
6006
Subtype of bearing 1 (suffix) SUFF1
RS
Shaft diameter 1 D5 (mm)
12
Type of bearing 2 (prefix) PREF2
6006
Subtype of bearing 2 (suffix) SUFF2
RS
Shaft diameter 2 D6 (mm)
12
Sort of bearing SRT-BEA
waterproof seal
Hub length L-HUB (mm)
105
Clamping length L-CLA (mm)
110
Material of the wheel (grouped) MAT-WH
polyurethane
Wheel material detail MAT-DET
vulkollan: For heavy duty 2-3 shifts/day/cold store with less noise, less vibrations
Material of the rim MAT-RIM
steel
Diameter of the rim D2 (mm)
63
Width of the rim W2 (mm)
105
Shape of the tread SH-TRED
cylindrical
Wheel profile PROF-WH
smooth
Gear ring present GEAR-PR
without gear ring
Number of bearings QTY-BEA
2
Groove for circlip present CIR-PR
NO
Reduction bushing present RBU-PR
YES
Material of the reduction bushing MAT-RBU
steel
Bushing between bearings present BU-PR
no
Suitable for coldstore use SUF
NO
Thread guards (FA-ready) FA
without thread guards
Grease nipple present NIP-PR
without grease nipple
