Direction of rotation of the thread RH/LH
right-handed
Metric diameter of the thread D1-M (mm)
10
Metric pitch of the thread Pm1 (mm)
1.5
Metric length between head and end L1-M (mm)
45
Total length of the bolt L3 (mm)
55
Fully threaded FULL-TA
NO
Type of bolt head TY-HEA
B1
Type of bolt end TY-END
B1
Strength class CLASS-ST
12.9
Type of material TY-MAT
steel
Metric width across flats WAF-M (mm)
8
Unit of measurement MI
metric
Length of the thread L2 (mm)
32
Largest thickness of the bolt head TH1 (mm)
10
Minimum diameter of the head D2 (mm)
16
Maximum diameter of the head D3 (mm)
16
Description of the bolt DESC
socket head cap screw
Shape of the head of the bolt SH-HEA
B
Shape of the bolt end SH-END
B
Thread locker present on the thread LOC-PR
NO
Movable lock washer present RING-PR
NO
