Type of the retaining ring
constant section
Cross section of the constant section retaining ring
rectangular (standing)
Shape of the constant section retaining ring
circular
Type of end 1 of the constant section retaining ring
007
Type of end 2 of the constant section retaining ring
007
Type of assembly of the retaining ring
external
Internal diameter of the ring in the unstressed state D1 (mm)
107
External diameter of the ring in the unstressed state D2 (mm)
117
Thickness of the ring TH1 (mm)
2.4
Maximum radial section width W2 (mm)
4.8
