Type of the retaining ring
tapered
Type of the tapered retaining ring
axial assembled
Main shape of the tapered retaining ring
DSH
Secondary shape of the tapered retaining ring
DSH-02
Type of assembly of the retaining ring
external
Internal diameter of the ring in the unstressed state D1 (mm)
55.8
Thickness of the ring TH1 (mm)
2
Maximum radial section width W2 (mm)
5.8
Lug hole diameter D6 (mm)
2.5
Minimum shaft diameter D3 (mm)
60
Maximum shaft diameter D3 (mm)
60
Groove diameter D5 (mm)
57
Groove width W3 (mm)
2.15
