Type of the retaining ring
constant section
Cross section of the constant section retaining ring
rectangular (standing)
Shape of the constant section retaining ring
circular
Type of end 1 of the constant section retaining ring
008
Type of end 2 of the constant section retaining ring
008
Type of assembly of the retaining ring
internal
Internal diameter of the ring in the unstressed state D1 (mm)
152
External diameter of the ring in the unstressed state D2 (mm)
165
Thickness of the ring TH1 (mm)
3.2
Maximum radial section width W2 (mm)
6.5
