Type of the retaining ring
tapered
Type of the tapered retaining ring
axial assembled
Main shape of the tapered retaining ring
DSH
Secondary shape of the tapered retaining ring
DSH-01
Type of assembly of the retaining ring
external
Internal diameter of the ring in the unstressed state D1 (mm)
57.8
Thickness of the ring TH1 (mm)
2
Maximum radial section width W2 (mm)
6
Lug hole diameter D6 (mm)
2.5
Minimum shaft diameter D3 (mm)
62
Maximum shaft diameter D3 (mm)
62
Groove diameter D5 (mm)
59
Groove width W3 (mm)
2.15
