Position of input water connection
R
Outer diameter of the input water connection D1 (mm)
38
Position of output water connection
L
Outer diameter of the output water connection D2 (mm)
38
Center distance between input and output water connection L3 (mm)
650
Length without accessories or mounting plates L1 (mm)
615
Height without accessories or mounting plates H1 (mm)
445
Width without accessories or mounting plates W1 (mm)
70
Total length with accessories or mounting plates L2 (mm)
700
Total height with accessories or mounting plates H2 (mm)
510
Total width with accessories or mounting plates W2 (mm)
180
Center distance between the 2 connections of the oil cooler L4 (mm)
214
Thickness of core of the radiator W3 (mm)
57
Center distance of the fins L5 (mm)
10
Diameter of the wind tunnel D3 (mm)
460
Length of the core of the radiator L6 (mm)
500
Height of the core of the radiator H3 (mm)
415
